Qhov siab hloov ceev tawg tau nto tshwj xeeb kho, thiab zoo li tshiab thiab zoo nkauj. Nrog nws cov kev ua haujlwm ruaj khov thiab lub thev naus laus zis technology, nws tau txais kev txaus siab los ntawm cov neeg siv khoom siv los ua cov khoom siv dav. Nws tuaj yeem yaj, tawg, sib xyaw thiab emulsify viscosity sib txawv cov ntaub ntawv los ntawm kev kub ceev kev sib hloov ntawm cov dispersion disc.
Kev Teeb Qauv:
- Tsav Lub Cev Muaj Zog: Siemens / ABB / DZ / tawg-pov thawj hom, thiab lwm yam.
- Lub cev muaj zog: 075KW-110KW
- Tsav Zog: 380V lossis 415V / 50Hz or60Hz
- Kev tswj hluav taws xob ceev: inverter ceev / hluav taws xob nrawm IPLC system
- Cov Kab Muag Ceev: 0〜1000 / 0〜1450 / 0〜2900RPM
- Ua Ntau Yam: 20L-10CBM ib pob
- Sealing Hom: ib leeg-kawg / ob-kawg lub tshuab foob, ntau hom kev foob tuaj yeem xaiv, tiv thaiv cov khoom tsis huv
- Ua Haujlwm Hom: High-speed shearing thiab paddle dispersing muaj zog sib xyaw, kev kub ceev kev tawg, kev sib xyaw zoo ntawm kev ncua kev kawm thiab muab cov khoom sib xyaw ua kua, nplua, thiab lwm yam.
- Cov Khoom Hu: SUS 304 / SUS 316L / 2205/2507 thiab lwm cov ntaub ntawv tshwj xeeb
- Bracket cov khoom siv: Q235-A / 304, thiab lwm yam. (Txhua tus hlau tsis muaj raws li GMP tus qauv)
- Kev Tswj Xyuas Hluav Taws Xob: Ua Ntej Hloov Lifting thiab Dispersing Tswjhwm, PLC Tswjhwm
- Cov khoom siv ua haujlwm: pneumatic rub tshuab, tsis siv neeg nqa lub zog, phau ntawv nqa khoom, tuav tuav cuab yeej, khawm twj cuab yeej, thiab lwm yam.
- Ntu Khoom Siv: lub tog raj kheej, reactor, lub tshuab nqus tsev, siab, cua sov, txias, khoom siv tswj kev ntsuas kub, thiab lwm yam.
KHOOM SIV PARAMETERS
|
Qauv No. |
Lub Zog Tsav (kw) |
Peev Xwm (L) |
Lub Cev Muaj Zog Ceev (RPM) |
Disperser Tawm Khoom Txoj kab uas hla (hli) |
Nyhav (kg) |
|
WRL-90 |
1.5 |
10〜50 |
2900 |
220 |
300 |
|
WRL-100 |
2.2 |
50-100 |
2900 |
250 |
350 |
|
WRL-120 |
4 |
100〜300 |
2900 |
280 |
400 |
|
WRL-140 |
7,5 |
300〜800 |
2900 |
300 |
500 |
Tsav Lub Cev Muaj Zog: AC lub cev muaj zog (tawg-pov thawj / tsis-tawg-pov thawj)
Lub cev muaj zog: 2.2KW - 100KW
Tsav Zog: 380V / 50HZ
Ceev: 0-1460RPM
Peev Xwm: 10-3000L
Cov Khoom Siv Hu: SUS304 stainless hlau
Bracket cov khoom: Q235-A
Ntawm qhov cua siab tsim, tsis muaj lub tshuab foob;
Nruab rau hauv qhov chaw ntsuas cua ； 30L-10.000L kev ua kom tau raws li cov kev xav tau sib txawv. Nws tuaj yeem siv nrog cov reactor thiab qhov ntev tuaj yeem raug kho;
Hom Ntaus: nruab rau hauv eccentric, ntsug, inclined, thiab lwm qhov chaw.
Kev kub ceev disperser tuaj yeem tsim lub zog muaj zog ntawm shear, muaj kev cuam tshuam thiab kev sib txhuam ntawm cov khoom siv thiab kev sib cais disc los ntawm kev sib hloov high-speed ntawm sawtooth dispersion disc, ua tiav lub hom phiaj ntawm kev tawg sai, kev tawg thiab kev sib xyaw ua ke. Cov khoom siv no muaj qhov tshwj xeeb ntawm cov qauv zoo nkauj, kev ua haujlwm ruaj khov, kev hloov pauv hloov ceev, kev siv lub zog tsawg, kev ruaj khov hydraulic nqa kev ua haujlwm, kev lag luam yooj yim, yooj yim disassembly dispersion disc, thiab yooj yim tu. Yog li ntawd nws yog dav siv rau kev sib xyaw thiab tawg nyob rau hauv txheej txheej, inks, adhesives, emulsions, cov ntaub ntawv zoo tshuaj, thiab lwm yam.
