Qhov siab hloov ceev tawg tau nto tshwj xeeb kho, thiab zoo li tshiab thiab zoo nkauj. Nrog nws cov kev ua haujlwm ruaj khov thiab lub thev naus laus zis technology, nws tau txais kev txaus siab los ntawm cov neeg siv khoom siv los ua cov khoom siv dav. Nws tuaj yeem yaj, tawg, sib xyaw thiab emulsify viscosity sib txawv cov ntaub ntawv los ntawm kev sib hloov highspeed ntawm cov dispersion disc.
Kev Kho Qauv FS30 Series:
1.Drive lub cev muaj zog: Siemens / ABB / DZ / tawg-pov thawj hom, thiab lwm yam.
2.Motor Zog: 0.75KW-110KW
3.Drive fais fab: 380V lossis 415V / 50Hz or60Hz
4.Speed Control Hom: inverter ceev / hluav taws xob nrawm / PLC system
5.Speed Ntau: 0〜1000 / 0〜1450 / 0〜2900RPM
6.Qhov Ntau Yam: 2 (^ - 10CBM ib pob
7.Txhais hom: ib qho kawg-ob / kawg-kawg cov tshuab foob, ntau hom kev foob tuaj yeem xaiv, tiv thaiv cov khoom tsis huv
8.Work hom: Kev kub siab shearing thiab paddle dispersing muaj zog sib xyaw, kev kub ceev kev tawg, kev sib xyaw zoo ntawm kev ncua kev kawm thiab muab cov khoom sib xyaw ua kua, nplua, thiab lwm yam.
9.Contact Material: SUS 304 / SUS 316L / 2205/2507 thiab lwm cov ntaub ntawv tshwj xeeb
10.Qhov khoom siv: Q235-A / 304, thiab lwm yam. (Txhua tus hlau stainless ua raws li GMP tus qauv)
11. Kev tswj hluav taws xob: Kev hloov chaw yooj yim Lifting thiab Dispersing Tswjhwm. PLC Tswjhwm System
12.Cov khoom siv ua haujlwm: pneumatic rub tshuab, tsis siv neeg nqa lub tshuab, nqa khoom nqa, tuav tuav cuab yeej, khawm twj ntaus, thiab lwm yam.
13.Qhov khoom siv ntxiv: lub tog raj kheej, reactor, lub tshuab nqus tsev, siab, cua sov, txias, khoom siv tiv thaiv kub thiab lwm yam.
Khoom Muaj Qauv
Tsav Lub Cev Muaj Zog: AC lub cev muaj zog (tawg-pov thawj / tsis-tawg-pov thawj)
Lub cev muaj zog: 2.2KW- 100KW
Tsav Zog: 380V / 50HZ
Ceev: 0- 1460RPM
Peev Xwm: 10 - 3000L
Cov Khoom Siv Hu: SUS304 stainless hlau
Bracket cov khoom: Q235-A
Ntawm qhov cua siab tsim, tsis muaj lub tshuab foob;
Nruab rau hauv qhov chaw ntsuas huab cua. 30L-10.000L kev ua haujlwm muaj peev xwm ua kom tau raws li cov kev xav tau sib txawv. Nws tuaj yeem siv nrog cov reactor thiab qhov ntev tuaj yeem raug kho;
* Cov ntaub ntawv saum toj no yog rau kev siv xwb thiab tuaj yeem kho tau raws li cov neeg yuav tsum tau ua.
* Cov khoom siv no tuaj yeem kho tau raws li cov neeg siv khoom cov khoom kom tau raws li cov kev xav tau ntawm cov txheej txheem, xws li xav tau ntau dua viscosity, txhim kho homogenization muaj nuj nqi, cov khoom kub rhiab thiab lwm yam uas yuav tsum tau ua.
Khoom Qauv Khoom
Kev kub ceev disperser tuaj yeem tsim lub zog muaj zog ntawm shear, muaj kev cuam tshuam thiab kev sib txhuam ntawm cov khoom siv thiab kev sib cais disc los ntawm kev sib hloov high-speed ntawm sawtooth dispersion disc, ua tiav lub hom phiaj ntawm kev tawg sai, kev tawg thiab kev sib xyaw ua ke. Cov khoom siv no muaj qhov tshwj xeeb ntawm cov qauv zoo nkauj, kev ua haujlwm ruaj khov, kev hloov pauv hloov ceev, kev siv lub zog tsawg, kev ruaj khov hydraulic nqa kev ua haujlwm, kev lag luam yooj yim, yooj yim disassembly dispersion disc, thiab yooj yim tu. Yog li ntawd nws yog dav siv rau kev sib xyaw thiab tawg nyob rau hauv txheej txheej, inks, adhesives, emulsions, cov ntaub ntawv zoo tshuaj, thiab lwm yam.
Tus Qauv Ua Haujlwm
• Nyob rau hauv cov nyhuv ntawm centrifugal quab yuam tsim los ntawm rotor tig ntawm lub nrawm, cov khoom siv hauv cov duab kos yog nqus rau hauv chav ua haujlwm los ntawm qhov chaw sab saud thiab qis noj ntawm chav ua haujlwm tib lub sijhawm.
• Lub zog muaj zog centrifugal cuam cov khoom siv los ntawm kev taw qhia radial mus rau qhov nqaim thiab npliag ntawm qhov stator thiab lub rotor. Raws li qhov kev txiav txim ntawm centrifugal extrusion thiab feem cuam tshuam, cov khoom yog thaum pib dispersed thiab emulsified.
• Muaj ib txoj kab khiav ceev nyob sab nraud qhov kawg ntawm lub qhov siab ceev, uas tsawg kawg 15m / s thiab mus txog 40m / s. tsim cov tshuab muaj zog thiab hydraulic shear, kua kev sib txhuam thiab cuam tshuam los kua muag, yog li ntawd cov khoom siv tau tawg yooj yim, emulsified, homogenized thiab crushed, thaum kawg nws tau ntiab tawm los ntawm stator qhov.
• Cov khoom txuas tawm tsis tu ncua los ntawm radial kev taw qhia ntawm lub siab nrawm, thiab cov kev taw qhia ntws tau hloov pauv raws li qhov tsis kam ntawm cov khoom nws tus kheej thiab lub thawv ntim. Nyob rau tib lub sijhawm, nyob rau hauv cov nyhuv ntawm qaum thiab qis axial suction tsim nyob rau hauv thaj chaw rotor, ob txoj kev sib nraus ntawm qhov siab los ntawm sab saud thiab qis yog tsim tau. Tom qab ob peb mus, cov khoom yog thaum kawg ua tiav ntawm cov txheej txheem ntawm kev tawg, emulsification, thiab homogenization.
Khoom Qhia Tawm
